Description
The RLW-001401 reactor from MTE is designed to ensure the reliable operation of industrial equipment by filtering power line disturbances and electrical noise. Its robust specifications and compact design make it suitable for various industrial applications where maintaining stable voltage and protecting machinery from electrical interference are crucial.
Features
- RoHS and REACH Compliant: Complies with environmental and safety standards.
- Wide Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Amperage Ratings: Available in ratings from 0.5 to 750 Amps.
- Transient Protection: Ideal for applications with single-phase drives, protecting against voltage spikes and power disturbances.
- Crossover Tables: Facilitates compatibility with various standard reactors.
- Epoxy Impregnation: Reduces audible noise, enhances structural integrity, and improves resistance to moisture.
- Compact and Lightweight: Designed for efficiency with reduced size and weight compared to traditional reactors.
- Versatile Mounting Options: Offers flexibility in installation to meet specific machine building requirements.
- Global Design: Suitable for international applications, meeting global standards for reliability and performance.
- Motor Protection: Designed for applications requiring lower horsepower protection.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 14 A
- Inductance: 0.00079 H (0.79 mH)
- Watt Loss: 32.7 W
- Impedance @ 240 VAC: 3%
- HP @ 240 VAC: 4 hp
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 2.8 lbs
- Gross Weight: 3.85 lbs
