Description
The RLW-001106 reactor from MTE belongs to the RLW series, renowned for its efficient filtering capabilities and compact design. It is suitable for a wide range of industrial applications requiring protection from power line disturbances.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards.
- Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Amperage Ratings: Covers a range from 0.5 to 750 Amps, catering to diverse application needs.
- Transient Protection: Ideal for safeguarding single-phase drives against voltage spikes and disturbances.
- Crossover Tables: Available to facilitate compatibility with other standard reactors.
- Epoxy Impregnation: Minimizes audible noise, enhances structural integrity, and improves resistance to moisture.
- Compact and Lightweight: Designed for space efficiency and ease of installation compared to conventional reactors.
- Versatile Mounting Options: Allows for flexible installation to meet specific machine building requirements.
- Global Design: Enables deployment worldwide, compliant with international standards.
- Motor Protection: Particularly suitable for smaller motor protection applications.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 11 A
- Inductance: 0.0042 H (4.2 mH)
- Watt Loss: 59.1 W
- Impedance @ 600 VAC: 5%
- HP @ 600 VAC: 7.5 hp
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 7.1 lbs
- Gross Weight: 7.8 lbs
