Description
The RLW-001103 reactor is designed to ensure stable operation and longevity of industrial machinery and electrical systems by filtering out power line disturbances. Its robust design and specifications make it suitable for various industrial applications where electrical noise reduction and voltage stabilization are critical.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards.
- Wide Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Amperage Ratings: Suitable for currents ranging from 0.5 to 750 Amps.
- Transient Protection: Effective for single-phase drives, protecting against voltage spikes and electrical disturbances.
- Crossover Tables: Available for compatibility with various standard reactors.
- Epoxy Impregnation: Minimizes audible noise, enhances structural integrity, and improves resistance to moisture.
- Compact and Lightweight: Designed for space efficiency and ease of installation, with reduced size and weight compared to traditional reactors.
- Versatile Mounting Options: Offers flexibility in installation to meet specific machine building requirements.
- Global Design: Designed for international use, meeting global standards for reliability and performance.
- Motor Protection: Suitable for applications requiring lower horsepower protection.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 11 A
- Inductance: 0.0021 H (2.100 mH)
- Watt Loss: 40.9 W
- Impedance @ 240 VAC: 5%
- Impedance @ 480 VAC: 3%
- HP @ 240 VAC: 3 hp
- HP @ 480 VAC: 7.5 hp
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 4.2 lbs
- Gross Weight: 4.2 lbs
