Description
Introducing advanced harmonic mitigation with the Matrix AP Passive Harmonic Filter.
Harmonics reduce efficiency, overheat equipment, and shorten the life of your electrical system. Traditional passive filters perform well at full load but lose effectiveness as load levels drop — and in real-world applications, systems rarely operate at 100% continuously.
The Matrix® AP is different.
Built with patented Adaptive Passive Technology, this three-phase harmonic filter automatically adapts to varying power loads, virtually eliminating harmonic distortion across the operating range. The result? Superior THID reduction, improved energy efficiency, extended equipment life, and compliance with IEEE-519 requirements.
Designed for performance and practicality, the Matrix AP runs cooler, installs easily, requires minimal maintenance, and is fully generator compatible. When power quality matters, this is the filter that delivers.
Key Features
- Patented Adaptive Passive Technology that adapts to varying power loads
- Industry-leading THID reduction performance
- Helps meet IEEE-519 harmonic compliance requirements
- Improves overall energy efficiency
- Extends service life of electrical equipment
- Generator compatible design
- Reduced heat generation compared to traditional passive filters
- Easy installation and low maintenance requirements
- Backed by a performance guarantee
Application Benefits
- Improves three-phase power quality
- Reduces system downtime
- Protects upstream and downstream equipment
- Optimizes system performance at partial and full loads
HSD0003CW10000
