Description
The MTE DVTK0200E is part of the advanced dV E-Series, designed specifically to protect motors by mitigating harmful effects of voltage spikes and reflective waves that are common in variable frequency drive (VFD) applications. This model is built to handle high current loads, making it ideal for large-scale industrial systems. The dV E-Series is recognized for its superior efficiency, compact size, and robust protection capabilities, ensuring prolonged motor life and reduced maintenance costs.
Key Features
- Harmonic Reduction: Reduces harmonic distortion caused by VFDs, aiding in compliance with industry standards and preventing damage to electrical components.
- Efficient Operation: Designed for up to 60% greater efficiency compared to similar products on the market.
- High Current Capacity: Suitable for systems requiring up to 200 amps, making it ideal for heavy-duty industrial applications.
- Compact and Durable: The enclosed unit is built to NEMA 3R standards, ensuring protection against environmental factors, and features a space-saving design.
- Versatile Voltage Compatibility: Operates across a broad voltage range of 208V to 600V.
Specifications
- Manufacturer: MTE Corporation
- Model: DVTK0200E
- Series: dV E-Series
- Voltage Range: 208-600V
- Current Rating: 200 A
- Frequency Range: 2-4 kHz
- Watt Loss: 175 W
- Horsepower Ratings:
- @ 240 VAC: 75 HP
- @ 480 VAC: 150 HP
- @ 575 VAC: 200 HP
- @ 600 VAC: 200 HP
- Terminals: Wire Leads
- Mounting: Surface mountable
- NEMA Rating: NEMA 3R
- Approvals: CE, cULus
