Description
The MTE DVTK0012E is a part of the dV E-Series, specifically designed to provide comprehensive motor protection in industrial applications. This dV/dt filter kit is engineered to safeguard motor windings and prevent insulation failures by mitigating reflective wave phenomena, reducing rise times, and controlling peak voltage levels. The dV E-Series stands out in the market due to its high efficiency, lightweight design, and compact footprint, making it a leading solution for protecting motors and extending the lifespan of cables and motor drives.
Key Features
- Triple Protection: Mitigates reflective waves, reduces rise times, and controls peak voltage to prevent motor damage.
- High Efficiency: Up to 60% more efficient compared to competitive products.
- Compact Design: 73% lighter and 35% smaller footprint, facilitating easier installation and integration.
- Performance Guarantee: Backed by MTE’s industry-leading Performance Guarantee and a three-year warranty for added reliability.
- Wide Voltage Range: Compatible with systems operating between 208V and 600V.
- Easy Installation: Provided as a kit for straightforward setup and integration.
Specifications
- Manufacturer: MTE Corporation
- Model: DVTK0012E
- Series: dV E-Series
- Voltage Range: 208-600V
- Current Rating: 12 A
- Frequency Range: 2-4 kHz
- Watt Loss: 86 W
- Horsepower Ratings:
- @ 240 VAC: 4 HP
- @ 480 VAC: 7.5 HP
- @ 575 VAC: 10 HP
- @ 600 VAC: 10 HP
- Terminals: Wire Leads
- Mounting: Surface mountable
- Approvals: CE, cULus
