A2A125TW – ABB | A2A 250 TMF 125-1250 3P F F UL

$855.25 CAD

The ABB Formula A2A 125 circuit breaker (1SDA069776R1 / A2A125TW-2) is a 2-pole 125A molded case circuit breaker with a 10 kA interrupt rating. Featuring fixed TMF trip units and front terminals, it provides compact UL-certified overcurrent protection.

2 in stock

SKU: A2A125TW Categories: ,

Description

The ABB Formula A2A 125 Molded Case Circuit Breaker (1SDA069776R1 / A2A125TW-2) is a reliable, compact 2-pole circuit breaker engineered for electrical protection in commercial and industrial distribution systems. Rated for 125 A continuous current with a 250 A frame size, it features fixed thermal and fixed magnetic (TMF 125-1250) trip units for consistent, maintenance-free overload and short-circuit protection.

Built to UL standards with a 10 kA short-circuit interruption rating, the A2A 125 incorporates fixed front terminals (F F) for straight-forward installation in electrical control panels, switchboards, and load centers. Its robust design provides long-term operational durability and dependable circuit performance.

Key Features

  • Formula A2 Frame Design: Compact 250 A frame size offers high performance in space-saving panel installations.
  • 125A Continuous Rating: Provides dependable 2-pole overcurrent protection for main feeds and branch circuits.
  • TMF Fixed Trip Unit: Equipped with fixed thermal and magnetic trip elements (125 A thermal / 1250 A magnetic threshold) for reliable system protection.
  • 10 kA Interrupt Rating: Delivers robust 10 kA short-circuit protection under UL standards.
  • Fixed Terminal Configuration: Front-fixed (F F) connections streamline power wiring and mounting in standard enclosures.
  • UL Certified: Meets stringent North American UL safety and manufacturing standards.

Specifications

Technical Specification Detail
Product Model A2A 250 TMF 125-1250 2P F F UL
Product ID (SKU) 1SDA069776R1
Alternate Catalog No. A2A125TW-2
Brand / Manufacturer ABB (Formula Series)
Product Type Molded Case Circuit Breaker (MCCB)
Amperage Rating 125 A
Number of Poles 2-Pole
Frame Size 250 A Frame (A2)
Trip Unit Type TMF (Fixed Thermal / Fixed Magnetic 125-1250)
Interrupt Rating 10 kA
Terminal Type Fixed Front Terminals (F F)
Certifications UL Listed
UPC 8015644704278
Weight 2.43 lbs
Dimensions 6 × 5 × 3 in
