Description
The MTE RLW-002806 reactor is designed to provide superior protection for electrical equipment by absorbing power line disturbances. With a current rating of 28 amps and an inductance of 1.6mH, this reactor is suitable for medium-current applications requiring high inductance. The open design ensures effective heat dissipation, making it ideal for environments where enclosure protection is not essential.
Features
- RoHS and REACH Compliant: Adheres to strict regulations on hazardous substances, ensuring environmental safety.
- Wide Voltage Compatibility: Suitable for standard voltage ranges from 208 to 690 VAC, offering versatility in various applications.
- Broad Amperage Range: Can be used in applications with current ratings from 0.5 to 750 amps.
- Transient Protection: Provides effective protection for single-phase drives against transient voltage spikes.
- Epoxy Impregnation: Reduces audible noise and enhances structural integrity and moisture resistance.
- Compact and Lightweight Design: Offers a state-of-the-art solution that is smaller and lighter than traditional reactors.
- Multiple Mounting Options: Designed to accommodate various mounting configurations for ease of installation.
- Global Design: Complies with international standards, facilitating global deployment.
- Motor Protection: Suitable for protecting motors with lower horsepower requirements.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 28 A
- Inductance: 1.6 mH
- Watt Loss: 8.8 W
- Horsepower Ratings:
- @ 600 VAC: 20 hp, 25 hp
- Impedance:
- @ 600 VAC: 5%
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 14.3 lbs
- Gross Weight: 15.6 lbs
