2002-1491-WAGO | End and intermediate plate; 0.8 mm thick; gray

2002-1491-WAGO | End and intermediate plate; 0.8 mm thick; gray

$ 1.27

The TOPJOB S 0.8 mm snap‑on terminal block in sleek gray delivers an ultra‑compact, high‑reliability connection solution for space‑constrained DIN‑rail installations. At only 0.8 mm pitch and 70 mm in height, it maximizes wiring density without sacrificing mechanical robustness. Housed in flame‑retardant Polyamide (PA66) with a UL94 V‑0 rating, it has passed stringent DIN EN 50155 and DIN EN 61373 railway‑grade shock and vibration tests. Weighing a mere 1.6 g, this terminal block is ideal for rolling stock electronics, industrial control cabinets and other mission‑critical systems demanding safe, tool‑free wiring.

44 in stock (can be backordered)

SKU: 2002-1491 Categories: , ,

Product Description

The TOPJOB S 0.8 mm snap‑on terminal block in sleek gray delivers an ultra‑compact, high‑reliability connection solution for space‑constrained DIN‑rail installations. At only 0.8 mm pitch and 70 mm in height, it maximizes wiring density without sacrificing mechanical robustness. Housed in flame‑retardant Polyamide (PA66) with a UL94 V‑0 rating, it has passed stringent DIN EN 50155 and DIN EN 61373 railway‑grade shock and vibration tests. Weighing a mere 1.6 g, this terminal block is ideal for rolling stock electronics, industrial control cabinets and other mission‑critical systems demanding safe, tool‑free wiring.

Key Features

  • Ultra‑narrow 0.8 mm pitch: Optimizes DIN‑rail wiring density

  • Snap‑on mounting: Tool‑free attachment to DIN‑35 rails

  • Flame‑retardant PA66 housing: UL94 V‑0 rated for maximum safety

  • Railway‑grade tested: Compliant with DIN EN 50155 & DIN EN 61373

  • Low fire load: 0.051 MJ minimizes energy in case of fire

  • Lightweight design: Just 1.6 g per unit

  • RoHS compliant: Environmentally friendly, no exemptions

Specifications

Category Parameter Value
Physical Data Width 0.8 mm (0.031 in)
Height 70 mm (2.756 in)
Depth 28.9 mm (1.138 in)
Mechanical Data Mounting Type Snap‑on onto DIN‑35 rail
Material Data Note See material specifications here
Color Gray
Material Group I
Insulation Material (main housing) Polyamide (PA66)
Flammability Class (UL94) V‑0
Fire Load 0.051 MJ
Weight 1.6 g
Environmental & Testing Electronic Equipment (DIN EN 50155) VDE 0115‑200:2022‑06
Shock & Vibration (DIN EN 61373) VDE 0115‑0106:2011‑04
• Noise‑like Vibration 5 Hz–150 Hz, 0.572 g, 5 h per axis
• Shock Half‑sine, 5 g, 30 ms, 3 pos./3 neg. per axis
Contact Fault & Voltage Drop Monitoring (before/after each axis) Passed
Commercial Data Product Group 22 (TOPJOB S)
PU (SPU) 100 pcs (25 pcs inner packs)
Packaging Type Box
Country of Origin CN (China)
GTIN 4055143234238
Customs Tariff Number 8538906000
Classification UNSPSC 39121702
eCl@ss 10.0 & 9.0 27‑14‑11‑33
ETIM 9.0 & 8.0 EC000886
ECCN No US Classification
Compliance RoHS Status Compliant, no exemption
Weight 0.003527 lbs
Dimensions 1.138 × 0.031 × 2.756 in
