2002-1392-WAGO | End and intermediate plate; 0.8 mm thick; orange

2002-1392-WAGO | End and intermediate plate; 0.8 mm thick; orange

$ 1.26

The TOPJOB S 0.8 mm snap‑on terminal block in vibrant orange combines ultra‑compact design with rugged performance for high‑density DIN‑rail applications. At just 0.8 mm pitch and 59 mm tall, it maximizes wiring capacity while occupying minimal space. Its flame‑retardant PA66 housing (UL94 V‑0) and proven compliance with DIN EN 50155 and DIN EN 61373 ensure dependable operation under extreme vibration, shock and temperature cycles. Weighing only 1.4 g, this terminal block is ideal for rolling stock electronics, industrial control panels and other mission‑critical systems requiring safe, tool‑free terminations.

100 in stock (can be backordered)

SKU: 2002-1392 Categories: , ,

Product Description

The TOPJOB S 0.8 mm snap‑on terminal block in vibrant orange combines ultra‑compact design with rugged performance for high‑density DIN‑rail applications. At just 0.8 mm pitch and 59 mm tall, it maximizes wiring capacity while occupying minimal space. Its flame‑retardant PA66 housing (UL94 V‑0) and proven compliance with DIN EN 50155 and DIN EN 61373 ensure dependable operation under extreme vibration, shock and temperature cycles. Weighing only 1.4 g, this terminal block is ideal for rolling stock electronics, industrial control panels and other mission‑critical systems requiring safe, tool‑free terminations.

Key Features

  • Ultra‑narrow 0.8 mm pitch: Maximizes connection density

  • Snap‑on mounting: Quick, tool‑free installation on DIN‑35 rails

  • High‑performance housing: Polyamide (PA66) UL94 V‑0 rated

  • Railway‑grade tested: Meets DIN EN 50155 & DIN EN 61373 standards

  • Low fire load: 0.043 MJ for reduced energy release in fire

  • Feather‑light: Only 1.4 g per unit

  • RoHS compliant: Environmentally friendly, no exemptions

Specifications

Category Parameter Value
Physical Data Width 0.8 mm (0.031 in)
Height 59 mm (2.323 in)
Depth 28.9 mm (1.138 in)
Mechanical Data Mounting Type Snap‑on onto DIN‑35 rail
Material Data Note See material specifications here
Color Orange
Material Group I
Insulation Material (main housing) Polyamide (PA66)
Flammability Class (UL94) V‑0
Fire Load 0.043 MJ
Weight 1.4 g
Environmental & Testing Electronic Equipment (DIN EN 50155) VDE 0115‑200:2022‑06
Shock & Vibration (DIN EN 61373) VDE 0115‑0106:2011‑04
• Noise‑like Vibration 5 Hz–150 Hz, 0.572 g, 5 h per axis
• Shock Half‑sine, 5 g, 30 ms, 3 pos./3 neg. per axis
Contact Fault & Voltage Drop Monitoring (before/after each axis) Passed
Commercial Data Product Group 22 (TOPJOB S)
PU (SPU) 100 pcs (25 pcs inner packs)
Packaging Type Box
Country of Origin CN (China)
GTIN 4055143234221
Customs Tariff Number 8538906000
Classification UNSPSC 39121702
eCl@ss 10.0 & 9.0 27‑14‑11‑33
ETIM 9.0 & 8.0 EC000886
ECCN No US Classification
Compliance RoHS Status Compliant, no exemption
Weight 0.003086 lbs
Dimensions 1.138 × 0.031 × 2.323 in
